Power Detectors

Laser Lines partner with Gentec-EO to offer their full range of industry leading thermopile power detectors for continuous measurement of laser powers from a few µW to 500 W. These are split into different series depending on the type of absorber, from sensitive detectors and standard broadband sensors, up to the highest damage threshold coatings available.



See the specifications tab for details of specific models, and the data sheets for complete specifications. For measuring powers above 500 W please see the high power page, or for more sensitive detectors please see the photo detector page.



XLP – Sensitive thermopile for measurements from 15 µW to 3 W



The XLP provides noise levels typical of photo detectors with the large bandwidth and power handling of a thermopile. An isolation tube is included and fibre adapters are available to directly connect fibre coupled lasers to the detector.



  • 5 µW noise equivalent power allows for accurate measurements from 15 µW upwards
  • IR filter available
  • Volume absorber version for high peak power pulsed lasers
  • Ideal for compact low power DPSS & diode lasers
  • Optional energy mode



UP-H – All-purpose standard broadband coated detectors for laser power measurement from 30 mW to 500 W



Available with five different apertures, and five different cooling options, the UP-H series of detectors is based on a modular format with increasing power capabilities. A large range of different combinations to suit varying power, space & cooling requirements means most laser measurement requirements can be solved by the UP-H series.



  • 10, 12, 19, 25, or 55 mm diameter aperture
  • Offered standalone or with heatsink, fan or water cooling modules for increased power capability
  • Includes the UP19K-15S-H5-D0 15 W detector, our most popular head for laser power measurement
  • Available with INTEGRA (USB/RS-232) or BLU (Bluetooth) connections
  • Suitable for a wide range of lasers, including Synrad, Photonics Industries & Lighthouse Photonics
  • Optional energy mode



UP-W – High damage threshold coated detectors for small beams and pulsed UV lasers up to 85 W



The UP-W series allows you to measure high power density lasers that would damage other sensors. With various sizes and cooling modules to suit different requirements, plus the most resilient coating on the market, the UP-W series handles lasers with small beams or high rep rate pulses with ease.



  • 100 kW/cm2 average damage threshold
  • 17 or 50 mm diameter aperture
  • Offered standalone or with heatsink, fan or water cooling modules for increased power capability
  • Designed for small beams, and pulsed UV and sub-nanosecond lasers
  • Optional energy mode



UP-VR – High peak power volume absorber detectors for high energy pulsed lasers up to 200 W



The UP-VR series is perfect for high energy density beams because, depending on wavelength, energy densities greater than 30 J/cm2 and peak power densities over 1 GW/cm2 can be handled. Degradation such as ablation that can be caused by high density repetitive pulses is minimised with the VR coating as the energy is distributed through the volume, rather than just across the surface.



  • 18 or 55 mm diameter aperture
  • Offered standalone or with heatsink, fan or water cooling modules for increased power capability
  • Available with INTEGRA (USB/RS-232) or BLU (Bluetooth) connections
  • Ideal for femtosecond and low rep rate, high energy pulsed lasers
  • Optional energy mode



All Gentec-EO detectors include an individual calibration certificate traceable to NIST standards with an 18-month expiry.



Compatible interfaces and monitors for Gentec-EO Power Detectors:

INTEGRA

BLU

MAESTRO

TUNER

UNO

S-LINK

P-LINK

M-LINK



For further details of these compatible monitors please see the monitors page.

Complementary products

UP-W Series
Spectral Range: 190 nm – 10 μm
ModelMax Power (W)Min Power (mW)Aperture Ø (mm)Cooling Type
UP17P-6S-W5-D063017Standalone
UP19K-15S-W5-D0153017Standalone
UP19K-30H-W5-D0303017Heatsink
UP50N-40S-W9-D04015050Standalone
UP19K-50L-W5-D0503017Heatsink
UP19K-50F-W5-D0503017Fan-Cooled
UP19K-50W-W5-D0503017Water-Cooled
UP50N-50H-W9-D05015050Heatsink
UP50N-50F-W9-D05015050Fan-Cooled
UP50M-50W-W9-D05015050Water-Cooled
UP-VR Series
Spectral Range: 266 nm – 2.5 μm
ModelMax Power (W)Min Power (mW)Aperture Ø (mm)Cooling Type
UP19K-15S-VR-D0156018Standalone
UP19K-30H-VR-D0306018Heatsink
UP55N-50S-VR-D05045055Standalone
UP55N-100H-VR-D010045055Heatsink
UP55N-150F-VR-D015045055Fan-Cooled
UP55M-200W-VR-D020045055Water-Cooled
